Sharpee - The Final Design Conversation with Claude
Note: I did agree not to post AI material, but this is an important conversation I had with Claude. It's not Claude's ramblings about Sharpee. It's a Q&A design session that I believe merits sharing in full.
Design Session: Text Service & Client Architecture
Date: 2026-01-13
Branch: chaining
Subject: The final design of how the text service and varying types of clients work together.
Participants: Dave Cornelson, Claude (Opus 4.5)
Status: Architecture finalized, ready for implementation
Overview
This session designed Sharpee's text output architecture from first principles, covering template syntax, TextBlock contracts, and client rendering. The design is inspired by FyreVM channel I/O (2009).
The Challenge
"We're going to test your ability to juggle complexity"
The goal: think through the entire text output system holistically:
- lang-en-us: Templates, formatters, prose
- text service: Middleware orchestration
- client: How we display the story
Scoping the Problem
CLI
"I think we can say CLI is simple and we've more or less already proven how it works"
CLI is solved - just concatenate TextBlocks with whitespace.
GLK
"I would say glk is an interesting IF thing, but it's worth an ADR with identified as the status"
GLK is a known future concern - park it as ADR-099 with status "identified".
Screen Reader / Accessibility
"There are a lot of blind IF players so I really love the idea of making Sharpee an easy path for authors to make games accessible"
Accessibility is a priority, not an afterthought. ADR-100 for screen reader support.
React / Electron
"the big one is react/electron and I think we have to consider them side by side"
React is the main focus. Works in both browser and Electron contexts.
Unified Template Syntax
The Problem
ADR-091 (Text Decorations) and ADR-095 (Message Templates) had overlapping concerns:
- ADR-095:
{modifier:placeholder}for formatters - ADR-091: Needed decorations on both placeholders AND literal text
The Solution
Dave: "yes let's figure out a unified syntax"
Three distinct syntaxes for distinct purposes:
{formatter:placeholder} - Transformations (a, the, list, cap)
[type:content] - Semantic decorations (item, room, npc)
*emphasis* / **strong** - Inline prose decoration
Can be combined:
[item:{a:item}] - Resolve placeholder, then mark as item-type
*{adverb}* - Resolve placeholder, then emphasize
Key insight: Formatters transform, decorations annotate. Different operations, different syntax.
Single TextService + Multiple Renderers
DRY Principle Applied
Dave: "let's add some basic developer principles (DRY) into the mix"
With multiple text services, you'd repeat:
- Template resolution logic
- Formatter logic (articles, lists)
- Decoration parsing
- Language layer integration
What actually differs per client: only rendering.
Architecture
┌─────────────────────────────────────────────────────────┐
│ lang-en-us │
│ Templates, formatters, noun types, prose │
└─────────────────────────────────────────────────────────┘
│
▼
┌─────────────────────────────────────────────────────────┐
│ TextService │
│ Resolves templates → parses decorations → TextBlocks │
│ (ONE implementation, shared) │
└─────────────────────────────────────────────────────────┘
│
▼
TextBlocks
│
┌─────────────────┼─────────────────┐
▼ ▼ ▼
┌─────────┐ ┌─────────┐ ┌─────────┐
│ React │ │ CLI │ │ JAWS │
│ Renderer│ │ Renderer│ │ Renderer│
└─────────┘ └─────────┘ └─────────┘
Each renderer is small - just maps decoration types to platform output.
Formalized TextBlock Contract
Dave: "do we formalize the text blocks?"
Yes - TextBlocks become a concrete, typed contract.
Package Location
@sharpee/text-blocks - pure interfaces, no implementation
Interface Design
type TextContent = string | IDecoration;
interface IDecoration {
type: string; // Open - 'em', 'item', 'photopia.red'
content: TextContent[]; // Can nest
}
interface ITextBlock {
key: string; // Channel - 'room.description', 'status.score'
content: TextContent[];
}
Language Agnostic
Dave: "do text blocks need to be language specific: textblocks-en-us"
No. TextBlocks are a universal container format. The prose inside is localized, but the structure is the same.
// Same ITextBlock shape, different language content
// English
{ key: 'action.result', content: ['You take the sword.'] }
// German
{ key: 'action.result', content: ['Du nimmst das Schwert.'] }
FyreVM Channel I/O Inspiration
Dave: "you just reinvented fyrevm channel IO Mr. Claude (though I actually invented it in 2009 with help from Tara McGrew and inspired by Jeff Panici)"
Credit where due! The architecture draws from proven design.
Channel = Block Key
{ key: 'room.description', content: [...] } // Channel: room
{ key: 'action.result', content: [...] } // Channel: action
{ key: 'status.score', content: [...] } // Channel: status
Key Conventions
| Prefix | Purpose | Client Routing |
|---|---|---|
room.* |
Room info | Main transcript |
action.* |
Action results | Main transcript |
status.* |
Status bar elements | Fixed header slots |
error |
System errors | Main transcript (styled) |
prompt |
Command prompt | Input area |
{story}.* |
Story-defined | Configurable |
Extensibility
Dave: "they start pre-defined, but I created a way for authors to make their own and use them in storytelling"
Same pattern in Sharpee:
- Core keys defined by platform
- Stories can define custom keys
- Clients render unknown keys with sensible defaults
Browser Architecture
Dave: "the engine bundles game and sharpee to {game}.js and runs in the browser (we've already done this and it's fast)"
No server. No API layer. Everything runs client-side.
┌─────────────────────────────────────────────────────────┐
│ {game}.js (bundled) │
│ Engine + WorldModel + Story + TextService + lang-en-us │
└─────────────────────────────────────────────────────────┘
│
│ on('turn-complete') → ITextBlock[]
▼
┌─────────────────────────────────────────────────────────┐
│ React Client │
│ Receives ITextBlock[], renders to DOM │
└─────────────────────────────────────────────────────────┘
Event-Based Client Communication
The IF Model
Dave: "in IF we have one stream of text blocks including any daemons and npcs - the client would never handle anything but one set of text blocks"
One stream. Everything mixed. Client just renders.
engine.on('turn-complete', (blocks: ITextBlock[]) => {
// One array - command results, daemons, NPCs, everything
setTranscript((prev) => [...prev, ...blocks]);
});
No routing logic. No "handling" different event types. Just:
- Receive blocks
- Append to transcript
- Render
Status Line Design
Not Special
Dave: "I see the status line as no different than any other rendered text block"
Status elements are just more blocks with status.* keys:
{ key: 'status.room', content: [{ type: 'room', content: ['West of House'] }] }
{ key: 'status.score', content: ['0'] }
{ key: 'status.turns', content: ['1'] }
Multiple Blocks, Not One Object
Dave: "B is the way I think" (choosing Option B: multiple sub-keyed blocks)
React routes by key to slots:
<StatusBar>
{blocks.filter(b => b.key.startsWith('status.')).map(renderToSlot)}
</StatusBar>
<Transcript>
{blocks.filter(b => !b.key.startsWith('status.')).map(renderBlock)}
</Transcript>
Story-Defined Colors (Photopia Pattern)
Dave: "think about how Sharpee would handle Adam Cadre's Photopia colors"
Photopia uses color as narrative. Authors need full creative control.
Solution
Authors define semantic color names in story config:
// stories/photopia/src/config.ts
export const storyColors = {
'photopia.red': '#cc0000', // Alley's scenes
'photopia.blue': '#0066cc', // Fantasy scenes
};
Templates use semantic names:
'[photopia.red:The light was red, like always.]'
Client looks up mapping, renders appropriately:
- Web: actual CSS color
- CLI: ANSI approximation
- Screen reader: announces "red text" or ignores
IDecoration Type is Open
interface IDecoration {
type: string; // Open - 'em', 'item', 'photopia.red'
content: TextContent[];
}
Type is open string, not enum. Core types are conventions, not constraints.
Decoration Types
Semantic vs Presentational
| Semantic | Presentational |
|---|---|
item |
em (italic) |
room |
strong (bold) |
npc |
underline |
command |
strikethrough |
direction |
super / sub |
| (story-defined) | (story colors) |
Decisions Summary
| Topic | Decision |
|---|---|
| Template syntax | Unified: {formatter:placeholder}, [type:content], *emphasis* |
| TextService | Single service, multiple renderers (DRY) |
| TextBlocks | Formalized ITextBlock contract, language-agnostic |
| Decoration type | Open string (not enum) for extensibility |
| Channel keys | Core prefixes + story-extensible |
| Client communication | Event-based: on('turn-complete') |
| Status line | Multiple status.* blocks, not special |
| Colors | Story-defined semantic names |
| Priority/role fields | Dropped (YAGNI) |
ADR Map
| ADR | Topic | Action |
|---|---|---|
| 091 | Text Decorations | Finalize - hybrid syntax decision |
| 095 | Message Templates | Update - align with 091 |
| 096 | Text Service | New - architecture, ITextBlock, channels |
| 097 | React Client | New - event-based, components |
| 099 | GLK Client | New - status: identified |
| 100 | Screen Reader | New - status: identified |
Package Structure
New Packages
@sharpee/text-blocks- Interfaces (ITextBlock, IDecoration)@sharpee/text-service- Single service implementation@sharpee/client-react- React client (greenfield)
Archived
text-services→ archivetext-service-browser→ archivetext-service-template→ archive
Key Quotes
"the Sharpee Way would be event based" - Dave
"you just reinvented fyrevm channel IO" - Dave (on the architecture)
"I'd toss the current implementation and design for what we're designing now" - Dave (clean slate)
"everything is greenfield Mr. Claude" - Dave
Next Steps
- Write/update ADRs (091, 095, 096, 097, 099, 100)
- Create
@sharpee/text-blockspackage - Create
@sharpee/text-servicepackage - Archive existing text-service packages
- Implement React client
This document preserves the design thinking and decisions from a pivotal architecture session.
