Integration Testing Exposes Flaw

Integration Testing Exposes Flaw

So far the unit testing had gone very smoothly. The architecture was holding up. Until we got to the integration testing, there were no major flaws.

But these last tests showed a shallow, but wide problem in our entities. We had been using the name as the id, but that won't scale and causes all kinds of testing and integration problems. So we discussed how we could update the entity.ID so that it would be stable.

We ended up with a new ADR (Architecture Decision Record) that explains it:


ADR-005: Entity ID System Design

Date: 2025-07-05
Status: Implemented (2025-07-06)
Implementation: Complete

Context

The world-model package needs a consistent system for identifying entities. Currently, tests use human-readable strings as IDs (e.g., 'player', 'kitchen', 'door1'), but this approach has several issues:

  1. Ambiguity: No clear distinction between entity IDs and display names
  2. Collision Risk: Multiple entities could accidentally use the same ID
  3. Author Experience: Future Forge authors will want to use meaningful names, not manage IDs
  4. Reference Resolution: Exits and doors reference other entities by string, unclear if ID or name
  5. Type Indication: IDs don't indicate what type of entity they represent

Decision Drivers

  • Developer Experience: Tests should be readable and easy to write
  • Author Experience: Forge authors should never see or manage IDs
  • Debugging: IDs should be short and indicate entity type
  • Uniqueness: System must guarantee no ID collisions
  • Flexibility: Support both programmatic and authored content

Considered Options

Option 1: Keep Current System (Human-Readable IDs)

  • Use meaningful strings as IDs ('player', 'kitchen')
  • Enforce uniqueness at creation time
  • Let Forge layer handle name-to-ID mapping

Pros:

  • Tests remain readable
  • No refactoring needed
  • Simple to understand

Cons:

  • Risk of collisions
  • No type indication
  • Mixes concerns (ID vs display name)

Option 2: Auto-Generated Numeric IDs

  • Generate IDs like 'entity_1', 'entity_2'
  • Maintain name-to-ID mapping
  • All methods use IDs only

Pros:

  • Guaranteed uniqueness
  • Clear separation of ID and name

Cons:

  • Hard to debug
  • Tests become unreadable
  • No type indication

Option 3: Type-Prefixed 3-Character IDs

  • Format: [type-prefix][2-char-base36] (e.g., r01, d01, i01, a01)
  • Auto-generated with type indication
  • Maintain bidirectional name-ID mapping

Pros:

  • Readable in logs and debugging
  • Type indication built-in
  • Guaranteed uniqueness
  • Short and efficient

Cons:

  • Requires refactoring
  • Tests need updating

Decision

We will implement Option 3: Type-Prefixed 3-Character IDs with the following design:

ID Format

[type-prefix][2-character-base36-counter]

Examples:
- r01, r02, r03 (rooms)
- d01, d02 (doors)
- i01, i02 (items)
- a01 (actors)
- c01 (containers)
- s01 (supporters)

Type Prefixes

const TYPE_PREFIXES = {
  'room': 'r',
  'door': 'd',
  'item': 'i',
  'actor': 'a',
  'container': 'c',
  'supporter': 's',
  'scenery': 'y',
  'exit': 'e'
};

API Design

class WorldModel {
  // Entity creation returns entity with generated ID
  createEntity(displayName: string, type: string = 'object'): IFEntity;

  // All methods use IDs only
  getEntity(id: string): IFEntity | undefined;
  moveEntity(entityId: string, targetId: string | null): boolean;

  // Helper for name resolution
  getId(name: string): string | undefined;
  getName(id: string): string | undefined;
}

Usage Pattern

// Creation
const kitchen = world.createEntity('Kitchen', 'room'); // Returns entity with id='r01'
const player = world.createEntity('Player', 'actor');  // Returns entity with id='a01'

// Usage with returned references
world.moveEntity(player.id, kitchen.id);

// Usage with name lookup (when needed)
world.moveEntity(world.getId('Player')!, world.getId('Kitchen')!);

Implementation Plan

  1. Phase 1: Implement ID generator and update WorldModel.createEntity
  2. Phase 2: Add name-to-ID mapping and helper methods
  3. Phase 3: Update all integration tests to use new pattern
  4. Phase 4: Update stdlib to use IDs consistently
  5. Phase 5: Document patterns for Forge integration

Consequences

Positive

  • Unique IDs: No collision risk
  • Debugging: Type-prefixed IDs make logs readable
  • Clean API: Clear separation between IDs and names
  • Future-Proof: Forge can build on top without changes

Negative

  • Refactoring Required: All tests need updating
  • Learning Curve: Developers must understand ID vs name
  • Verbosity: Some test code becomes slightly longer

Neutral

  • Test readability changes from 'kitchen' to kitchen.id
  • Error messages will show IDs like 'r01' instead of 'kitchen'

Notes

  • The 3-character limit provides 46,656 possible IDs per type (36^2), far exceeding any IF game needs
  • Case-insensitive name lookup will prevent common errors
  • Forge will completely hide this ID system from authors
  • Migration can be done incrementally by updating tests one at a time

Implementation Details (Added 2025-07-06)

What Was Built

  1. ID Generation System
    • Auto-generates IDs like r01, d02, i03 based on entity type
    • Maintains per-type counters in WorldModel
    • Throws error on overflow (>1295 entities per type)
  2. Name/ID Mapping
    • Bidirectional maps: nameToId and idToName
    • Case-insensitive name lookup
    • Automatic mapping on entity creation
  3. Entity Name Resolution
    • entity.name getter with priority chain:
      1. attributes.displayName (highest)
      2. Identity trait name
      3. attributes.name
      4. ID (fallback)
  4. Backwards Compatibility
    • Old createEntity(id, name) signature still works with deprecation warning
    • Save/load system preserves ID mappings
    • Automatic ID system rebuild for old saves
  5. Test Infrastructure
    • Helper functions: getTestEntity, expectEntity, moveEntityByName
    • Updated all integration tests
    • Updated fixture functions

Key Insights

  1. Separation of Concerns Works: The existing architecture already separated names (for users) from IDs (for system), making the refactor smooth.
  2. Command System Unchanged: The CommandValidator already used entity.name for resolution and entity.id for operations, so no changes needed.
  3. Test Readability Maintained: Helper functions keep tests readable while using the new system.

Actual ID Limits

  • Format: [prefix][00-zz] gives 1296 IDs per type (36^2)
  • More than sufficient for any IF game
  • Clear error on overflow

Migration Path

  1. Update entity creation calls
  2. Use entity references or name resolution
  3. Update test assertions
  4. Old saves auto-migrate

We decided to go ahead with the refactoring which touched a lot of code and tests, but that's now completed and we're able to move forward. Cost us a day, but it was worth it.

I still need to re-run all of the unit tests and then we go back to the engine and story to finish the entire chain of architecture.
